Oracle Dashboard in Graylog

As you know for the SE version is not covered performance in OEM, so you can not see the real-time DB performance.
This is a limitation (license) commissioned by Oracle for the SE, but given the continued growth and spread of this release, I thought a way to fill a bit this absence.
Graylog is an open source software for log management that lets you index, historical context, for further analysis, any type of log and not structured, servers and platforms.
My idea:


  • logstash to capture SQL statements connecting to the database and then send them to the server graylog
  • Graylog server to centralize all SQL statements in real-time and create dashboards.

I created a repository on github where explain these steps for installation and related resources used in my working setup.

When I connect my instance graylog I can check each sql statement executed ASH (I deliberately obscured sql statement):






















Creating dashboards with Graylog, based on what you want to analyze, the reading is much easier and immediate:



























Yuo can find all here in Graylog Market....

Enjoy !!!

lunedì 6 luglio 2015

Welcome Standard Edition 2 release 12c.

Dopo un week-end bollente non solo a livello meteo, Oracle ha sancito la dismissione della versione Standard Edition e Standard Edition One.
E' stata creata una nuova release Standard Edition 2 dove però la differenza a mio avviso più importante è a livello di license infatti, mentre per le vecchie  release SE si poteva arrivare a 4 socket, nella nuova Standard Edition 2 il limite è stato abbassato a 2 socket.
Altre info importanti sono presenti nel blog di Ludovico Caldara

Questa notizia stata bollente in questo week-end,  creando così hastag  #orclse2 per stare aggiornati.

Stay Tuned.



UPDATE – 8 Luglio 2015

Sono stai fatti dei cambiamenti importanti in merito, vi consiglio di seguire direttamente sul sito ufficiale del supporto Oracle per i Doc1905806.1 and Doc742060.1




mercoledì 20 maggio 2015

Oracle Ash on @graylog2 by @logstash

Dai un'occhiata al Tweet di @Albertofro: https://twitter.com/Albertofro/status/601027107112751105?s=09

giovedì 11 settembre 2014

Policy-Managed Database Webinar - Oracle Database 11g

Ieri si è svolto uno dei pochi webinar in Italiano su Policy-Managed Database  tutto questo grazie al RACSig e soprattutto grazie a Ludovico Caldara.
Webinar molto interessante ed esposizione molto chiara a precisa.
Per chi non ha potuto essere presente, può andare a vederlo qui, nel canale dedicato in YouTube all'evento.
L'evento è stato seguito anche in diretta twitter da ITOUG, @it_oug.
Ancora grazie per la splendida opportunità.

martedì 22 aprile 2014

AUTOTRACE - DB TIME

Today I write this post in English for better explain, (I hope) my previous post Oracle - Windows Sort Pushed Rank access, after Jocelyn's question about AUTOTRACE and statistics like DB TIME.
I used SqlDeveloper to capture autotrace in my previous post, and this is a trick in new version 4 of this software but I tryed to reproduce the same in sqlplus but in effect it's very hard or it's not simple like I think, so


[oracle@localhost ~]$ sqlplus pmuser/oracle@PDB1

SQL*Plus: Release 12.1.0.1.0 Production on Tue Apr 22 10:28:55 2014

Copyright (c) 1982, 2013, Oracle.  All rights reserved.

Last Successful login time: Tue Apr 22 2014 10:17:34 +02:00

Connected to:
Oracle Database 12c Enterprise Edition Release 12.1.0.1.0 - 64bit Production
With the Partitioning, OLAP, Advanced Analytics and Real Application Testing options

PDB1@ORCL> alter session set statistics_level= ALL;

Session altered.

PDB1@ORCL> set linesize 100;
PDB1@ORCL> SET AUTOTRACE ON
select  owner,object_name,object_id from t2
order by owner,object_name fetch first 5 rows only;PDB1@ORCL>   2

OWNER
----------------------------------------------------------------------------------------------------
OBJECT_NAME
----------------------------------------------------------------------------------------------------
 OBJECT_ID
----------
APEX_040200
APEX
     93296

APEX_040200
APEX$ARCHIVE_CONTENTS
     94132

OWNER
----------------------------------------------------------------------------------------------------
OBJECT_NAME
----------------------------------------------------------------------------------------------------
 OBJECT_ID
----------

APEX_040200
APEX$ARCHIVE_CONTENTS_IDX1
     94136

APEX_040200
APEX$ARCHIVE_HEADER

OWNER
----------------------------------------------------------------------------------------------------
OBJECT_NAME
----------------------------------------------------------------------------------------------------
 OBJECT_ID
----------
     94130

APEX_040200
APEX$ARCHIVE_HISTORY
     94137



Execution Plan
----------------------------------------------------------
Plan hash value: 3975347511

-----------------------------------------------------------------------------------------
| Id  | Operation   | Name | Rows | Bytes |TempSpc| Cost (%CPU)| Time |
-----------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT  | | 89325 |    24M| |  1265   (1)| 00:00:01 |
|*  1 |  VIEW    | | 89325 |    24M| |  1265   (1)| 00:00:01 |
|*  2 |   WINDOW SORT PUSHED RANK| | 89325 |  3140K|  4216K|  1265   (1)| 00:00:01 |
|   3 |    TABLE ACCESS FULL  | T2 | 89325 |  3140K| |   418   (1)| 00:00:01 |
-----------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   1 - filter("from$_subquery$_002"."rowlimit_$$_rownumber"<=5)
   2 - filter(ROW_NUMBER() OVER ( ORDER BY "OWNER","OBJECT_NAME")<=5)


Statistics
----------------------------------------------------------
  80  recursive calls
   0  db block gets
       1596  consistent gets
       1512  physical reads
   0  redo size
 890  bytes sent via SQL*Net to client
 543  bytes received via SQL*Net from client
   2  SQL*Net roundtrips to/from client
  12  sorts (memory)
   0  sorts (disk)
   5  rows processed

PDB1@ORCL>
In this case we have no db time in Statistics, while in SqlDeveloper there are.
Now I don't know why in this case this parameter is missing, but could be a nice workaround like this:
[oracle@localhost ~]$ sqlplus pmuser/oracle@PDB1

SQL*Plus: Release 12.1.0.1.0 Production on Tue Apr 22 11:40:11 2014

Copyright (c) 1982, 2013, Oracle.  All rights reserved.

Last Successful login time: Tue Apr 22 2014 10:29:23 +02:00

Connected to:
Oracle Database 12c Enterprise Edition Release 12.1.0.1.0 - 64bit Production
With the Partitioning, OLAP, Advanced Analytics and Real Application Testing options

PDB1@ORCL> set linesize 100
PDB1@ORCL> set heading off
PDB1@ORCL> select sys_context('USERENV','SID') from dual;

45

PDB1@ORCL> SET AUTOTRACE ON
select  owner,object_name,object_id from t2
order by owner,object_name fetch first 5 rows only;
PDB1@ORCL>   2
APEX_040200
APEX
     93296

APEX_040200
APEX$ARCHIVE_CONTENTS
     94132

APEX_040200
APEX$ARCHIVE_CONTENTS_IDX1
     94136

APEX_040200

APEX$ARCHIVE_HEADER
     94130

APEX_040200
APEX$ARCHIVE_HISTORY
     94137



Execution Plan
----------------------------------------------------------
Plan hash value: 3975347511

-----------------------------------------------------------------------------------------
| Id  | Operation   | Name | Rows | Bytes |TempSpc| Cost (%CPU)| Time |
-----------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT  | | 89325 |    24M| |  1265   (1)| 00:00:01 |
|*  1 |  VIEW    | | 89325 |    24M| |  1265   (1)| 00:00:01 |
|*  2 |   WINDOW SORT PUSHED RANK| | 89325 |  3140K|  4216K|  1265   (1)| 00:00:01 |
|   3 |    TABLE ACCESS FULL  | T2 | 89325 |  3140K| |   418   (1)| 00:00:01 |
-----------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   1 - filter("from$_subquery$_002"."rowlimit_$$_rownumber"<=5)
   2 - filter(ROW_NUMBER() OVER ( ORDER BY "OWNER","OBJECT_NAME")<=5)


Statistics
----------------------------------------------------------
  79  recursive calls
   0  db block gets
       1597  consistent gets
       1516  physical reads
   0  redo size
 890  bytes sent via SQL*Net to client
 543  bytes received via SQL*Net from client
   2  SQL*Net roundtrips to/from client
   7  sorts (memory)
   0  sorts (disk)
   5  rows processed

PDB1@ORCL> set autotrace off
PDB1@ORCL> select name, value from  v$statname a, v$mystat b
where
        b.value <> 0
and     b.statistic# = a.statistic#
and b.SID = 45;

Requests to/from client        31
logons cumulative         1
logons current          1
opened cursors cumulative      919
opened cursors current        11
user calls         51
recursive calls              5978
recursive cpu usage        27
pinned cursors current        11
session logical reads             8394
CPU used when call started       29
CPU used by this session       30
DB time         249

user I/O wait time       136
non-idle wait time       136
non-idle wait count       731
session connect time       1398159611
process last non-idle time      1398159611
session uga memory          2933728
session uga memory max          2933728
messages sent          2
session pga memory         10064008
session pga memory max         10260616
enqueue requests        89
enqueue releases        84
physical read total IO requests      695

physical read total bytes        16588800
cell physical IO interconnect bytes       16588800
db block gets         36
db block gets from cache       36
db block gets from cache (fastpath)       2
consistent gets              8358
consistent gets from cache            6856
consistent gets pin             3327
consistent gets pin (fastpath)            2915
consistent gets examination            3529
consistent gets examination (fastpath)           3438
consistent gets direct             1502
logical read bytes from cache        56459264

physical reads              2025
physical reads cache       523
physical reads direct             1502
physical read IO requests      695
physical read bytes         16588800
db block changes        37
consistent changes        20
free buffer requested       531
dirty buffers inspected        12
pinned buffers inspected        1
hot buffers moved to head of LRU           2957
free buffer inspected       638
commit cleanouts         2

commit cleanouts successfully completed       2
switch current to new buffer        2
physical reads cache prefetch       20
shared hash latch upgrades - no wait      84
calls to kcmgcs        155
calls to kcmgas          6
calls to get snapshot scn: kcmgss           1817
redo entries         12
redo size              5420
redo synch time (usec)         1
redo synch time overhead (usec)      146
redo synch time overhead count (  2ms)       1
redo synch writes         2

redo write info find         1
file io wait time          1178238
Number of read IOs issued      192
temp space allocated (bytes)         3145728
undo change vector size             3712
no work - consistent read gets            4677
deferred (CURRENT) block cleanout applications      1
IMU Flushes          1
IMU ktichg flush         1
CLI Thru Wrt          1
table scans (short tables)       42
table scans (long tables)        1
table scans (direct read)        1

table scan rows gotten           102715
table scan blocks gotten            1603
table fetch by rowid             2311
table fetch continued row       37
cluster key scans       187
cluster key scan block gets      190
rows fetched via callback      724
lob writes          1
lob writes unaligned         1
index fetch by key       962
index scans kdiixs1       852
HSC Heap Segment Block Changes       10
sql area evicted        29

CCursor + sql area evicted       18
session cursor cache hits      850
session cursor cache count       49
cursor authentications        31
buffer is pinned count       723
buffer is not pinned count            5962
workarea memory allocated      658
workarea executions - optimal      133
parse time cpu         10
parse time elapsed        66
parse count (total)       487
parse count (hard)        71
execute count              1086

bytes sent via SQL*Net to client          12451
bytes received via SQL*Net from client           8880
SQL*Net roundtrips to/from client      31
sorts (memory)        283
sorts (rows)             91107

109 rows selected.

PDB1@ORCL>
In this case we have all statistics DB TIME also. We need to ask to Jeff Smith more explanation about... Your comments are welcome, as usual.... HTH

venerdì 17 gennaio 2014

Oracle - Windows Sort Pushed Rank access

Dopo una attenta lettura di un'ottimo post nel blog di Cristian, mi sono incuriosito per uno strano comportamento di un explain plan di un test, per la funzione, WINDOW SORT PUSHED RANK in Oracle 12c.
Seguendo un articolo di Tom Kyte dove veniva illustrato la funzione fetch first X rows (only top n query) e cercando di riprodurre lo stesso comportamento nella nostri Oracle 12c ci siamo imbattuti in qualche stranezza.


create table t2 as select * from all_objects;

create index idx_t2 on t2(owner,object_name);

SET AUTOTRACE ON
select  owner,object_name,object_id from t2
order by owner,object_name fetch first 5 rows only;

Autotrace Enabled
Shows the execution plan as well as statistics of the statement.


OWNER           OBJECT_NAME                     OBJECT_ID
APEX_040200 APEX                         88901
APEX_040200 APEX$ARCHIVE_CONTENTS         89728
APEX_040200 APEX$ARCHIVE_CONTENTS_IDX1 89732
APEX_040200 APEX$ARCHIVE_HEADER         89726
APEX_040200 APEX$ARCHIVE_HISTORY         89733

Plan hash value: 3975347511

-----------------------------------------------------------------------------------------
| Id  | Operation                | Name | Rows  | Bytes |TempSpc| Cost (%CPU)| Time     |
-----------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT         |      | 86477 |    23M|       |  3191   (1)| 00:00:01 |
|*  1 |  VIEW                    |      | 86477 |    23M|       |  3191   (1)| 00:00:01 |
|*  2 |   WINDOW SORT PUSHED RANK|      | 86477 |    11M|    13M|  3191   (1)| 00:00:01 |
|   3 |    TABLE ACCESS FULL     | T2   | 86477 |    11M|       |   412   (1)| 00:00:01 |
-----------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   1 - filter("from$_subquery$_002"."rowlimit_$$_rownumber"<=5)
   2 - filter(ROW_NUMBER() OVER ( ORDER BY "OWNER","OBJECT_NAME")<=5)

Note
-----
   - dynamic statistics used: dynamic sampling (level=2)

   Statistics
-----------------------------------------------------------
               2  CCursor + sql area evicted
              83  CPU used by this session
              83  CPU used when call started
              87  DB time
              25  Number of read IOs issued
              88  Requests to/from client
              88  SQL*Net roundtrips to/from client
              63  buffer is not pinned count
            1104  bytes received via SQL*Net from client
           35629  bytes sent via SQL*Net to client
               8  calls to get snapshot scn: kcmgss
              13  calls to kcmgcs
        15081472  cell physical IO interconnect bytes
            1585  consistent gets
            1510  consistent gets direct
               2  consistent gets examination
               2  consistent gets examination (fastpath)
              75  consistent gets from cache
              73  consistent gets pin
              22  consistent gets pin (fastpath)
               2  enqueue releases
               2  enqueue requests
               6  execute count
            1074  file io wait time
             331  free buffer requested
               2  index scans kdiixs1
          614400  logical read bytes from cache
            1573  no work - consistent read gets
             164  non-idle wait count
               1  non-idle wait time
               6  opened cursors cumulative
               2  opened cursors current
               2  parse count (hard)
               4  parse count (total)
               1  parse time cpu
               2  parse time elapsed
              76  physical read IO requests
        15081472  physical read bytes
              76  physical read total IO requests
        15081472  physical read total bytes
              25  physical read total multi block requests
            1841  physical reads
             331  physical reads cache
             280  physical reads cache prefetch
            1510  physical reads direct
               7  recursive calls
               1  recursive cpu usage
              -1  session cursor cache count
               3  session cursor cache hits
            1585  session logical reads
              51  shared hash latch upgrades - no wait
               3  sorts (memory)
           90762  sorts (rows)
            1571  table scan blocks gotten
           93514  table scan rows gotten
               1  table scans (direct read)
               2  table scans (short tables)
              89  user calls
               5  workarea executions - optimal
Ci siamo chiesti come mai nell'esempio proposto venisse utilizzato l'indice appositamente creato mentre nel nostro no. Nemmeno aggiornando le statistiche la situazione non cambiava. Sono andato a verificare in v$parameter il parametro dell'optimizer e l'ho trovato ALL_ROWS la cosa mi ha subito insospettito quindi ho provato con
alter session set OPTIMIZER_MODE = FIRST_ROWS

SET AUTOTRACE ON
select  owner,object_name,object_id from t2
order by owner,object_name fetch first 5 rows only;


Autotrace Enabled
Shows the execution plan as well as statistics of the statement.

OWNER           OBJECT_NAME                     OBJECT_ID
APEX_040200 APEX                         88901
APEX_040200 APEX$ARCHIVE_CONTENTS         89728
APEX_040200 APEX$ARCHIVE_CONTENTS_IDX1 89732
APEX_040200 APEX$ARCHIVE_HEADER         89726
APEX_040200 APEX$ARCHIVE_HISTORY         89733

Plan hash value: 2588503356

----------------------------------------------------------------------------------------
| Id  | Operation                     | Name   | Rows  | Bytes | Cost (%CPU)| Time     |
----------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT              |        | 89906 |    24M| 69551   (1)| 00:00:03 |
|*  1 |  VIEW                         |        | 89906 |    24M| 69551   (1)| 00:00:03 |
|*  2 |   WINDOW NOSORT STOPKEY       |        | 89906 |  3160K| 69551   (1)| 00:00:03 |
|   3 |    TABLE ACCESS BY INDEX ROWID| T2     | 89906 |  3160K| 69551   (1)| 00:00:03 |
|   4 |     INDEX FULL SCAN           | IDX_T2 | 89906 |       |   524   (1)| 00:00:01 |
----------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   1 - filter("from$_subquery$_002"."rowlimit_$$_rownumber"<=5)
   2 - filter(ROW_NUMBER() OVER ( ORDER BY "OWNER","OBJECT_NAME")<=5)

   Statistics
-----------------------------------------------------------
              19  Requests to/from client
              19  SQL*Net roundtrips to/from client
               4  buffer is not pinned count
               9  buffer is pinned count
             463  bytes received via SQL*Net from client
           32492  bytes sent via SQL*Net to client
               2  calls to get snapshot scn: kcmgss
               2  calls to kcmgcs
               5  consistent gets
               2  consistent gets examination
               2  consistent gets examination (fastpath)
               5  consistent gets from cache
               3  consistent gets pin
               3  consistent gets pin (fastpath)
               1  cursor authentications
               2  execute count
               1  index scans kdiixs1
           40960  logical read bytes from cache
               3  no work - consistent read gets
              19  non-idle wait count
               2  opened cursors cumulative
               1  opened cursors current
               2  parse count (total)
               5  session logical reads
               1  sorts (memory)
             855  sorts (rows)
               6  table fetch by rowid
              20  user calls
               3  workarea executions - optimal

Adesso l'indice viene utilizzato correttamente e il piano di esecuzione è migliorato sensibilmente. Presumo che nell'esempio proposto da Tom Kyte questo parametro fosse impostato con appunto FIRST_ROWS.
